PDLH Series Aluminum Lever Chain Hoists

0.25 to 0.75 Metric Tons Capacity

1.5 Meter Standard Lift

Aluminum Lever Chain Hoist PDLH Series

0.25 to 0.75 Metric Ton

1.5 Meter Standard Lift

1 Chain Fall

Made to the Standard: EN13157

● High-strength aluminum alloy shell for light weight.
● Compact frame design for light weight and high strength.
● 6 gear reduction system so the lever force is small and the lever distance is reduced.
● Double pawl braking system–smooth braking.
● High strength–the life of the hoist exceeds 1500 EU standard fatigue tests.

PDLH Series Aluminum Lever Chain Hoists
