Stainless Swage Fittings

Gate Terminal

316 Stainless Steel




Item Size A B
Wire
C D Wire Weight
S0744-0003 1/8" 2.09" 1.26" 1.06" 0.58" 1/8" 0.10 lb
S0744-0004 5/32" 2.37" 1.50" 1.06" 0.58" 5/32" 0.15 lb
S0744-0005 3/16" 2.64" 2.01" 1.06" 0.58" 3/16" 0.20 lb
