Marine Pneumatic Capstan

Right Angle Open

For Vessel or Pier Installations

Marine Pneumatic Capstan

Working Load Limit of 2,000 to 20 Tons and Larger
Vertical or Horizontal Capstan Head
Any Power Supply - Various Configuration


Information Needed for Marine Capstan Quotations


DESCRIPTION

DIRECT DRIVE
A direct-drive design increases the efficiency of the capstan winch and eliminates drive chains or bull gears to maximize power output.

ANY ANGLE
The rope can leave the drum at any angle, enabling the operator to stand in the most appropriate, out of line of sight location. For safety the load line shall be the bottom wrap on the drum, and the lead line going to the operator will be the top wrap on the drum

GEAR REDUCERS
All capstan winches utilize high-efficiency worm, helical, helical-worm or helical-bevel reducers plus high-capacity, anti-friction bearings designed for long life, low noise and higher output torque.

OPTIONS

THRU OR SEMI THRU DECK
Through deck configuration with capstan motor or motor and gear below deck

CONTROLS
Capstans can be supplied with start/stop, foot-operated controls of the “deadman” variety. If the operator’s foot moves off the switch, the capstan will stop. This type of control allows the operator to use two hands on the rope, for optimum control.

EXPLOSION PROOF
Fully explosion-proof motors and controls are available for applications in hostile or volatile environments.

TORQUE LIMITATION
Capstans can be supplied with a variable frequency drive (VFD) package. The VFD controls the amount of current that the motor can draw, limiting the amount of torque that the electric motor can produce.

Marine Pneumatic Capstan
