Model 936

Spinner 2 Oil Filter

Up to 1 GPM or 3.8 Liters Per Minute

Extends Oil Change Interval - Extends Engine Life

Re-Usable Rotor

Paper Insert for Easy Bowl Cleaning

Up to 250cc of Contaminants

LCB (Level Control Base) Included (Air Supply Required)
LCB Allows for Faster Oil Return with Smaller Return Line

Product should be sized to circulate oil sump 4 to 5 times per hour.

Spinner Model 936 with capacity of 1 GPM is for Oil Sump size 12 to 15 Gallons.

3 Connections To Make:
Oil Inlet - 1/2 NPT Female
Oil Outlet - 1/2 NPT Female
Air Inlet - 1/4 NPT Female

Centrifugal Oil Purification System - Removes Particles Down to .1 Micron

Extends Oil Change Interval - Extends Engine Life

Operates on engine oil pressure

For: Engine lubricants, gear oils, machining fluids, hydraulic oils, quench oils

Engine mounted or side mounted

Operates on oil pressure only

Remove particles down to 1/10 of a micron

Remove carbon and soot

Use in addition to your full flow filter system

Stand alone pump assisted units available

Protects Machinery:

Reduces wear up to 50%

Increases engine / component life

Helps reduce frequency of maintenance and repair

Extends Operating Intervals

Keeps fluids and additives effective longer

Prolongs full flow filter life

Centrifuge requires minimal service

Eliminates Waste

Permanent, cleanable and reusable

No media or filter element to replace

Protects the environment by reducing disposable waste

Sample of Dirty Spinner Bowl

Remove particles down to .1 micron
