Stainless Turnbuckle

Toggle & Toggle Turnbuckle

Chromed Bronze Body and Stainless Ends


Item A Size B Adjust C D E BL Weight
S0785-0007 1/4" 7.12" 3.5" 0.35" 0.23" 2,750 0.30 lb
S0785-0009 5/16" 8.25" 3.8" 0.4" 0.31" 4,300 0.45 lb
S0785-0010 3/8" 9.75" 4.4" 0.56" 0.37" 6,500 0.65 lb
S0785-0013 1/2" 11.62" 4.62" 0.63" 0.47" 10,300 1.60 lb
S0785-0016 5/8" 7.5" 16.25" 0.8" 0.62" 17,000 2.95 lb
