Stainless Turnbuckle

Toggle & Swage Turnbuckle

Chromed Bronze Body and Stainless Ends


Item A Size B Adjust C D E F Wire Weight
S0786-0703 1/4" 8.37" 3.5" 0.35" 0.23" 1/8" 0.27 lb
S0786-0704 1/4" 8.81" 3.5" 0.35" 0.23" 5/32" 0.28 lb
S0786-0705 1/4" 8.87" 3.50" 0.35"
S0786-0904 5/16" 9.25" 3.8" 0.4" 0.31" 5/32" 0.42 lb
S0786-0905 5/16" 9.62" 3.8" 0.4" 0.31" 3/16" 0.44 lb
S0786-1005 3/8" 11.5" 4.4" 0.56" 0.37" 3/16" 0.63 lb
S0786-1006 3/8" 10.25" 13.25" 0.51" 0.37" 7/32" 0.65 lb
S0786-1007 3/8" 11.5" 4.4" 0.56" 0.37" 1/4" 67 lb
S0786-1307 1/2" 13" 4.62" 0.63" 0.47" 1/4" 1.48 lb
S0786-1308 1/2" 12.50" 16.50" 0.60" 0.50" 9/32" 1.20 lb
S0786-1309 1/2" 13.75" 4.62" 0.63" 0.47" 5/16" 1.5 lb
S0786-1610 5/8" 15.00" 19.00" 0.76" 0.62" 3/8" 3.00 lb
