Swageless Fittings

Swageless Stud and Wall Mount

316 Stainless Steel


ITEM A B C D E F WT
S0766-0703 1/8" 1/4" 4.20" 6.75" 0.25" 1.58" 0.25
S0766-0704 5/32" 1/4" 4.20" 6.75" 0.25" 1.58" 0.27
S0766-0905 3/16" 5/16" 4.32" 7.30" 0.31" 1.75" 0.50
S0766-1007 1/4" 3/8" 4.90" 8.00" 0.38" 2.00" 0.74
