How PM&I Can Help Prevent Delays

Y Strainer

600 Y1 Series

 1/2 inch to 2 inches
Carbon Steel, Stainless Steel, Low Carbon Steel, Alloy 20
NPT and Socketweld
Standard Screen Sizes: (Other Sizes Available)
1/2" to 1 1/2" = 1/32" perforations
2" = 3/64" perforations
Pressure Drop vs. Flow Rate Open Area Ratios
Replacement Strainer Baskets
