1500 Lbs. Y Strainer

1500 Y2 Series

1500 Lbs. Y Strainer
 2 inch to 6 inch
Carbon Steel and Stainless Steel
Flanged, Ring Joint and Buttweld

Standard Screen Sizes: (Other Sizes Available)
2" to 3" = 3/64" perforations
4" to 6" = 1/8" perforations

Pressure Drop vs. Flow Rate Open Area Ratios

1500 Lbs. Y Strainer 1500 Lbs. Y Strainer

Replacement Strainer Baskets
