Aluminum Tie Down Points

Cargo, Aircraft, Vehicle Aluminum Securing Points

 TP25SS Flush Round Aluminum Securing Point

TP-40SS Flush Round Aluminum Securing Point

Flush Aluminum Rectangular Pocket

Flush Aluminum Round Pocket

Flush Aluminum Round Pocket

Flush Aluminum Rectangular Pocket

Part TP-25SS Part TP-40SS Part FR-064.15

Aluminum Casting - Flush

Aluminum Casting - Flush

Aluminum Casting - Flush

4.23 Inch Diameter

5.5 Inch Diameter

8.375 Inch Length x 4.750 Inch Width

1/2 Inch Diameter Stainless Pin 1/2 Inch Diameter Stainless Pin 3/4 Inch Diameter Stainless Pin
Breaking Load: 6140 Lbs Breaking Load: 5150 Lbs Breaking Load: 20,790 Lbs





Flush Aluminum Rectangular Pocket Flush Aluminum Rectangular Pocket Raised Aluminum Round Securing Point
Flush Aluminum Rectangular Pocket Flush Aluminum Rectangular Pocket

Raised Aluminum Round Securing Point

Part FR-064.155 Part FR-064.155HT Part SC-01

Aluminum Casting - Flush

Aluminum Casting - Heat Treated - Flush

Aluminum Casting

8.375 Inch Length x 4.750 Inch Width

8.375 Inch Length x 4.750 Inch Width

7.5 Inch Diameter

1 Inch Diameter Stainless Pin 1 Inch Diameter Stainless Pin 1/4 Inch Pin (Bent)
Breaking Load: 29,688 Lbs. Breaking Load: Approximately 37,000 Lbs. Breaking Load: 5530 Lbs


aluminum tie down pocket

flush aluminum container foundation

Flush Rectangular Pocket

Steel Fitting Weldable to Aluminum

Aluminum Container Foundations

Part FR-064

Made to Specification

Flush, Dovetail, Raised

Aluminum Casting - Square Bottom - Flush

Weld into Aluminum Deck

Weld into Aluminum Deck

6.58" x 6.05" Rectangular

Provide with Tri Metal Ring Steel Fittings with Tri Metal Plate or Ring
5/8 Inch Stainless Steel Pin

Breaking Load: 10,421 Lbs





This catalog page includes:

aluminum tie down, aluminum tiedown, aluminum securing point, aluminum cargo tie down, aluminum cargo tiedown, aluminum tie down point, aluminum tiedown point, aluminum aircraft tie down, aluminum vehicle tie down, aluminum securing point, aluminum cargo securing points, aluminum tie down point, flush round aluminum pocket, flush square aluminum pocket, raised round aluminum securing point, aluminum fittings for aluminum hull vessels, aluminum container foundations, container foundations for aluminum deck,
